Features

    • 3" x 4.1 Ib. channel crossmembers, 12" O.C. for lengths up to 18'
    • 5" x 3" structural angle side longitudinal for lengths up to 18'
    • 4" x 5.4 Ib. channel crossmembers, 12" O.C. for lengths 20' & longer
    • 6" x 8.2 Ib. Structural channel side longitudinal for lengths 20' & longer
    • External stake pockets and rub rails
    • 34" structural channel chassis sills
    • 3/16" formed front & rear aprons
    • Pressure-treated pine lumber deck
    • All lighting is LED rubber-mounted and fully compliant with NTEA and federal standards
    • Our products come acid etched, phosphate washed, with corrosion resistant epoxy primer and then baked for a strong superior finish
    • 3 year limited warranty
    Bulkhead
    • 12-gauge panel with formed stiffeners and structural tubing uprights
    • Available in 40", 48", or 56" heights
    • Slotted dual-window design
    • Window delete option

    Options

    • Steel floor
    • Scissor hoist conversion
    • Gooseneck door
    • Gooseneck hitch plate
    • 42" stake racks

    Weights and Measurements

    LengthModelSill HeightCab to Axle (CA)Bed Dimensions (W x L)Body Width (OA)Weight Wood DeckWeight Steel Floor
    9'6"DEPW096965"60"92 x 114"96"1200 Ibs1500 Ibs
    10'6"DEPW106965"84-102"92 x 126"96"1460 Ibs1860 Ibs
    12'6"DEPW126966"84-108"92 x 150"96"1720 Ibs2250 Ibs
    14'6"DEPW146967"102-138"92 x 174"96"1980 Ibs2550 Ibs
    16'6"DEPW166967"120-150"92 x 198"96"2240 Ibs2840 Ibs
    18'6"DEPW186967"138-156"92 x 222 "96"2500 Ibs3130 Ibs
    20'6"DEPW206968"144-168"92 x 246"96"2870 Ibs3500 Ibs
    22'6"DEPW226968"150-186"92 x 270"96"3150 Ibs3790 Ibs
    24'6"DEPW246968"Min. 168"92 x 294"96"3430 Ibs4050 Ibs
    26'6"DEPW266968"Min. 186"92 x 318"96"3710 Ibs4350 Ibs
