LANDSCAPER BODIES

• 5" x 6.7 Ib. channel long sills
• 3" x 4.1 Ib. channel crossmembers
• 10-gauge two-piece steel floor
• 12-gauge steel side plates and bulkhead
• 54" curb side door
• Structural tubing rear corner posts
• 3/16" rear crossmember/apron with reverse and tail light knockouts
• 3/8" D-rings located at each inside corner
• All lighting is LED rubber-mounted and fully compliant with NTEA and federal standards
• Available with class 20 and 40 single-cylinder hoists
• Mounted & painted subframe for ease of installation
• Includes all mounting hardware and brackets
• Our products come acid etched, phosphate washed, with corrosion resistant epoxy primer and then baked for a strong superior finish
• 3 year limited warranty

Tailgate

• Full height barn doors with cam latch and lockable hasp
• Secondary spring pin latch on right side door
• Doors open 270 degrees

• Adjustable bolt-on, 12-gauge cab protector for ease of install and future optional custom overhang
• Integrated tie-down slots for up to three 6cu ft. wheel barrows
• Pre-punched tarp mounting provisions

• 12" or 42" cab shield
• Two-way 20" dump gate with upper barn doors
• Manual or spring-loaded tarp assembly
• Coal chute(s), installed (painted)
• Pull-out 2 step ladder on curb side access door
• Subframe/hoist/pump delete options
